Simple optical transmission path for high energy throughput

*Minimal reduction in baseline energy

*Wide measurement range

*No integral reflective surfaces to consider or keep clean

*Uses conventional sample position of a spectrophotometer

*Useable in most simple Bio spectrophotometers

Patented Hydro-danamic design with two window vertical geometry

*Effective and automatic elimination of any excess sample from measurement area

*No additional optical components to consider

*Fits directly into a standard 10 mm path length cell holder

Ergonomic Demountable Magnetic Assembly

*No external mechanical,locking or retaining devices required

*Positive physical window positioning

*Accurate and reproducible path lengths

*Sample is located in a clearly defined physical area

*Easy filling and cleaning of sample area

Available in 0.5,0.2 and 0.125 mm certifiable path lengths

*Effective nominal volumes of 2.5,1.0 and 0.6 ul respectively

*Optical path can be validated to a high degree of accuracy with Starna certified references

Available in 8.5 and 15 mm Z heights

*Designed for use in a wide variety of spectrophotometers
